SPECIFICATIONS
Infrared Touch Interactive Board
Infrared Touch Intelligent Blackboard
It connects freely the interactive whiteboard and traditional blackboard, supports traditional chalk writing on the side green board, and displays on the touch screen or interactive whiteboard at the same time, also can save the writing in the PC. Through this solution, writing content is converted to a digital page and shared via QR code, this solution can be combined with an interactive whiteboard and also can be combined with IFPD. give much more convenience to the users and make the class much more effective, interactive, and attractive.
- Model: N-105I-S
- Active size: 105″
- Display Area: 2446.96*1030.82mm
- Display Ratio: 16:9
| Actual size | 105″ |
| Display Area | 2446.96*1030.82mm |
| Resoultion | 5120*2160 |
| Response Time | 5ms |
| Display Ratio | 16:9 |
| Refresh Rate | 60Hz |
| Display Color | 1.078 (8-bit+Dithering) |
| Color Gamut | NTSC (Typ) 72% |
| Contrast | 5000:1 |
| View Angle | 178° (H/V) |
| Brightness | 500cd/m2 |
| Service Life | 26000h |
| Touch Sensor | IR Touch |
| Support OS | windows 11/window 10/window 8/window 7/windows XP/Android/Linux/Mac OS X/Chrome |
| Touch Points | 20 Points |
| Minimum Identifier | 3mm |
| Writing Tools | Pen or Finger adn other opaque objects |
| Response Time | Less than 5ms |
| Display Color | 1.078 (8-bit+Dithering) |
| Touch Accurancy | 41mm (more than 90% touch area) |
| Writing Height | 3.5mm |
| communicate | Full speed USB |
| surface Hardness | 7H |
| Output Coordinates | 32767 (W)*32767 (D) |
| CPU | Octa core ARM Cortex-A73 |
| Android Version | Android 10.0 |
| Frequency | 2.8GHz |
| GPU | ARM Mali-G52 Mp2 (MC6) |
| RAM | 8GB DDR4 |
| ROM | 128GB |
| Wifi | IEEE802.11an 2.4/S GHz |
| Cast Hotspot | IEEE802.11a/b/g/n Dual band 2.4GHz/5GHz Dual band |
| Bluetooth | BT:v2.1+EDR/BT:v3.0/BT:v3.0+HS0/BT:v4.0/BT:v5.0 |
| Software | Professional whiteboard software: rich functions, such as writing, drawing, shape, erase, gesture recognition, annotation, QR code scanning, recording etc.. Professional wireless presentation software: wireless transmission of signal form other devices of iOS, Android, Windows, macOS, chrome and ubuntu os to the interactive board |
| VLC Module (optional) | VLC Module:12M/48M HD Camera; 13M auto tracking camera; audio:8 microphone sound array system, audio pickup range up to 12M |
| Windows pro | Intel i3 CPU, 6th Gen, 3.7G Hz, DDR4-8G RAM, 256G SSD/ Intel i3 CPU, 8th Gen, 3.6G Hz, DDR4-8G RAM (optional) |
| Windows max | Intel i5 CPU, 6th Gen, 2.7G Hz, DDR4-8G RAM, 256G SSD/ Intel i5 CPU, 8th Gen, 2.8G Hz, DDR4-8G RAM (optional) |
| Windows Maxplus | Intel i7 CPU, 6th Gen, 3.4G Hz, DDR4-8G RAM, 256G SSD/ Intel i7 CPU, 8th Gen, 3.2G Hz, DDR4-8G RAM (optional) |
| Input Interface | HDMI*2, USB*2, RS232*1, RJ45*1, Earphone terminals CVBs*2,Touch Port*1 |
| Output Interface | Earphone terminals CVBs*1, RCA*1 |
| Front Panel | PC/AN-USB*2, PC-USB 3.0*1, HDMI Input*1,Touch Port*1, Remote control receiver*1, Type C |
| Type C |
| Power Supply | Ac 100V-240V, 50/60Hz |
| Power Consumption | Lessthan 300W |
| Front Speaker | 12W*2/15W*2 |
| Accessories | Infrared touch, remote control, manual, power cable, stand (optional) |
| VESA (mm) | 800*600 |
| Net Product Dimension (mm) | 2508.84*1156.36*103.6 |
| Net Product Dimension (kg) | 89.5 |
